SCORPIUS GO 430

The Scorpius GO 430 is the big brother of the Scorpius GO family and features a substantial upgrade in the lumens department. This no-frills, easy to use heavy-duty work light comes into its own in industries such as construction, forestry, agriculture, and material handling. Just like the rest of its siblings, the Scorpius GO 430 has a square form factor, pedestal or pendulum mounting, and three light pattern options. The Scorpius GO 430 produces zero emissions (EMC CISPR 25 class 5) and its light output is 3000 lumens.

TECHNICAL DATA
Theoretical Lumens Output: 4800 lm
Operational Lumens Output: 3000 lm
Colour Temperature: 5000 K
Nominal Voltage: DC 12V/24 V
Input Voltage: DC 9 - 16 V/18 - 32 V
Power Consumption: 44 W
Nominal Current at 24V =1.5A, 12V=2.8A
Connector Built-in Deutsch DT-2 (2-pin)
Mount Single Bolt M8
Shock 60G
Vibration 8Grms 24-2000Hz
Lens Grilamid® (registered
trademark of EMS-GRIVORY)
Body / Housing Aluminium
Weight 0.79 kg
IP Rating IP68, IP6K9K
Salt Spray Test ISO 9227 240H
EMC CISPR 25 Class 5, EN12895,
ISO 13766, ISO 14982, ISO
7637-2
Operating Temperatures -40°C... +85°C (Full Power
-40°C... +50°C)
Electronics Isolated

KEY FEATURES

• Dimmable & Cost-effective all-rounder
• Operational lumens output: 3000lm
• Pure performance in a compact design
